DC Charger Connector
-
MIDA 300A 350A GBT Charging Gun GBT DC Charging Connector
Rated current : 300A,350AOperating voltage : 1000V DCInsulation resistance : >2000MΩTerminal temperature rise :<50KWithstand voltage :3200VWaterproof degree:IP54Contact impedance:0.5MΩ Max -
CUL 300A 350A 385A CCS1 Cable DC Charging Connector For Fast DC Charger Station
Rated current :250A,300A,350A,385AOperating voltage : 1000V DCInsulation resistance : >2000MΩTerminal temperature rise :<50KWithstand voltage :3200VWaterproof degree:IP54Contact impedance:0.5MΩ Max -
150A 200A 250A CHAdeMO DC Charger Cable DC Fast Charging Plug
- Rated Current:150A 200A 250A
- Rated voltage:600V
- Therminal temperature rise:<50K
- Protection Degree:IP55
- Withstand voltage:2000V
- Working temperature:-30°C ~+50°C
- Contact impedance:0.5m Max
- Certificate:CE Approved
-
200A 250A CHAdeMO DC Fast Charging Connector EV Charger Plug
- Rated Current:200A
- Rated voltage:600V
- Therminal temperature rise:<50K
- Protection Degree:IP55
- Withstand voltage:2000V
- Working temperature:-30°C ~+50°C
- Contact impedance:0.5m Max
- Certificate:CE Approved
-
600A Tesla NACS Charger Cable Liquid-cooled Charging cable for DC Fast Charger NACS Charging
Rated current : 600AOperating voltage : 1000V DCInsulation resistance : >2000MΩTerminal temperature rise :<50KWithstand voltage :3200VWaterproof degree:IP67Contact impedance:0.5MΩ Max -
300A Tesla DC Fast Charger Cale-UL Rated NACS Connector
Rated current : 300AOperating voltage : 1000V DCInsulation resistance : >2000MΩTerminal temperature rise :<50KWithstand voltage :3200VWaterproof degree:IP54Contact impedance:0.5MΩ Max -
300A CCS Combo 2 Connector 300A CCS2 EV Plug Fact Charging Gun
Product Model:MIDA-CSS2-EV300P
Rated Current:300A
Operated Voltage:DC1000V
Withstand Voltage:3200V
Waterproof Degree:IP55
Certification:TUV,CE Approved -
250A GBT Charging Cable GB/T Gun For 240kW DC Charger Station
Rated current : 80A 125A 150A 200A,250AOperating voltage : 1000V DCInsulation resistance : >2000MΩTerminal temperature rise :<50KWithstand voltage :3200VWaterproof degree:IP54Contact impedance:0.5MΩ Max -
350A Tesla DC Fast Charger Cale-UL Rated NACS Connector
Rated current : 80A 125A 150A 200A,250A,350AOperating voltage : 1000V DCInsulation resistance : >2000MΩTerminal temperature rise :<50KWithstand voltage :3200VWaterproof degree:IP67Contact impedance:0.5MΩ Max -
250A CCS Combo 2 Connector IEC 62196-3 250A CCS2 EV Plug DC Fast Charging Gun
Product Model:MIDA-CSS2-EV250P
Rated Current:250A
Operated Voltage:DC1000V
Withstand Voltage:3200V
Waterproof Degree:IP55
Certification:TUV,CE Approved -
300A CCS 2 Fast Charger Connector Combo 2 Gun EV Charging Plug
Product Model:MIDA-CSS2-EV300P
Rated Current:300A
Operated Voltage:DC1000V
Withstand Voltage:3200V
Waterproof Degree:IP55
Certification:TUV,CE Approved -
250A 300A CCS Combo 2 Type 2 DC Fast Charging Gun
Product Model:MIDA-CSS2-EV250P,MIDA-CSS2-EV300P
Rated Current:250A/300A
Operated Voltage:DC1000V
Withstand Voltage:3200V
Waterproof Degree:IP55
Certification:TUV,CE Approved
