Electric 180kw 240kw Dc Charger Station Truck Public Ev Fast 240kw 480kw 360kw 600kw Dc Charging Station with Advertising Screen

Short Description:

  • Rate Power:DC Fast Charging Station
  • Input voltage range:260-480V AC
  • Wide temperature range::-30ºC to +65ºC
  • AC Grid Frequency:40-65Hz
  • Output Voltage:150V-1000V
  • protocol compatible:OCPP1.6
  • Output current:125A-500A
  • Power Factor:≥0.99
  • Leakage current:≤10mA
  • Power Frequency Withstand Voltage:2500VAC


Download as PDF

Product Detail

FAQ

Product Tags

Model MIDA-AD-60KW MIDA-AD-80KW MIDA-AD-120KW MIDA-AD-160KW MIDA-AD-180KW
Technicalfeatures
MaxPower 60kw 80kw Up120KW Up160KW Upto180KW
Input/Output 400VAC±10%-50/60Hz-3phase
Powerfactor 0.98
Efficiency >95%
Measuringaccuracy Level1
Outputvoltagerange CCS:200~1000VDC
Outputcurrentrange 200A*2 0-250A*2 0-250A*2 0-250A*2 0-250A*2
Communication Ethernet/WIFI/4G/OCPP1.6J(wss)
Userinterface RFIDcardandAPP
Display LCD7inchTouchScreen&55-inchadvertisingscreen
Versatility IEC61851/IEC62196/ISO1511/DIN70121/EN61000-6-4:2007
EnergyMeter CEcertified
RCD TypeAorTypeB(optional)
Securitydesign Over/undervoltageprotection,overloadprotection,currentleakage

protection,groundingprotection,lighteningsurgeprotection
DCPlugs CCS1*2Cable5M
Physicalproperties
Warranty 2years
Applicationplace Outdoor
Soundnoise <70DBinalldirections
Operating

temperature

 -20℃to+50℃
Humidity Max.95%(non-regulating)
Dimensions 2077*850*597mm
Package

Dimension

 2220*1200*800mm
NetWeight 225Kg 235Kg 275Kg 290Kg 325Kg
GrossWeight 285Kg 295Kg 335Kg 355Kg 375Kg
